MWGC1 Magnetic Welding Ground Clamp

Availability:
Quantity:

e

Model

Dimension(mm)

A B C D E

Current (A)

Net Weight

(kg)

Pull Off Force

(kg)

MWGC1-200 60*32*64*36*35 200 0.28 30
MWGC1-300 60*32*71*36*42 300 0.38 40
MWGC1-600 62*34*95*36*55 600 0.58 70
Name MWGC1 Magnetic Welding Ground Clamp
Application

This Welding Ground Clamp is designed to hold a ground cable to any ferro-magnetic surface. Using patented technology, this device has strong holdingpower as well as a great amount of shear force holding strength to reduce sideways movement.

Features

1.Applicable to clamp both flat and round workpieces.

2. Simple operation. On/Off controlled by the switch.

3.Time and cost saving.
